[Refurbished] Ferguson Ariva T20 HD TDT2 DVB-T2 1080p Mediaplayer
The Ferguson Ariva T20 receiver is compatible with the latest transmission technologies (DVB-T2 or TDT2). These technologies will soon be widely used due to the very good image quality of the DVB-T2 standard.
€58.20
€89.54
Save 35%
Tax included
Reference
ferguson-ariva-t20
Brand
Ferguson
[Refurbished] Ferguson Ariva T20 HD TDT2 DVB-T2 1080p Mediaplayer
€58.20
€89.54
Save 35%
Ariva T20 is a very simple device to use and install. Simply connect the terrestrial antenna to the box and the HDMI cable to a TV to enjoy high quality picture and sound. Ariva T20 is one of few terrestrial TV receivers with a lower price range that has a digital LED display on the front panel. The timeshift function and multimedia support makes the receiver a home entertainment center. With advanced built in solutions, it is possible to record your favorite programs on the external memory as well as view photos and play music and movies in HD. The receiver supports video playback in HD and with subtitles in many popular standards.
From the cheapest receivers available on the market, the Ariva T20 distinguishes by providing support for Dolby Digital Plus (in the near future essential function to decode TV programs)
Features
- Digital LED display on front panel.
- Support for Dolby Digital Plus.
- Support for DVB-T/T2.
- Signal upscaling - upscaling of PAL signal to a resolution of 720p or 1080p
- Operation timers
- Support of teletext and subtitles
- Support of MPEG-2, MPEG-4, MPEG-4 AVC/H.264 standards
- Multimedia support - just plug a USB drive with the media to display your photos, videos or music and have a good time with your loved ones. Of course subtitles are supported.
Inputs/Outputs
- ANT IN
- LOOP OUT
- Digital Audio Output (Coaxial)
- HDMI
- SCART
- Analog Audio/Video
- USB 2.0
Remote control
Ariva T20 is supplied with an ergonomic remote control RCU 120. The remote control provides a high comfort of operating the receiver.
Specifications
| Ferguson | Ariva T20 |
|---|---|
| STB Type | DVB-T/T2 Receiver |
| Main Chipset | MSD7T01 |
| SMPS Type | Adapter |
| Dimension (width x depth x height) | 135 mm x 87 mm x 30 mm |
| Net Weight | 500 g |
| CPU frequency | 576 MHz |
| Flash Memory | 4 MB |
| SDRAM Memory | 1PC 64X16 Mbit |
| Tuner Type | RF836 |
| Frequency Range | 174~230 MHz, UHF: 470~862 MHz |
| Input Impedance | 75 Ω |
| Active Ant Power | 5VDC |
| RF input | -78~-20dBm |
| RF Frequency | 7 MHz and 8 MHz |
| Modulation | QPSK, 16QAM, 64QAM, 256QAM |
| External Drive Capacity | up to 500 GB |
| Media Containers | MP3, WMA, JPEG, BMP, AVI, MKV |
| Video Decode | H.264 HP do L4, MPEG-4 plus, MPEG-2 MP HL, MPEG-1 |
| Video Resolution | 480i/480p/576i/576p/720p/1080i/1080p |
| Video Outputs | HDMI 1.3, SCART |
| Audio Outputs | Audio Output Coaxial, L/R(Scart) |
| Audio Decode | MPEG-1 (layer 1/2/3), WMA, AC3 |
| Power Input | 220~240V, 50/60Hz |
| Max Energy Consumption | 5 W |
| Humidity | <95% |
Data sheet
- Weight
- 300 g
810 g - Power
- DC 12 V / 5 W max.
DC 12 V / PoE (IEEE802.3af) / 9.1W (ICR+IR+WDR+IVS) - Resolution
- 2 Mpx (1920x1080)
- Temp. operation
- -40º C ~ +60º C
- Degree of protection
- IP67, IK10
Interior - Dimensions
- 97 mm × 99.5 mm × 46.6 mm
- Transfer Rate
- 3 kbps-17664 kbps
- Power supply
- DC 12 V / 5 W max.
- Material
- Body: Metal | Housing: Plastic
Metal and Plastic
Métal et plastique - Range
- ULTRA
- Alarm
- No
- Functions
- 3D-DNR, DWDR, BLC, HLC, White Balance, ROI, Privacy Mask
- Video output
- 1 x BNC HDTVI / HDCVI / AHD / CVBS
- Audio
- 2 IN / 2 OUT / Built-in micro, Built-in Speaker
Built-in microphone / 1 RCA output
Microphone intégré / 1 Sortie RCA - Image sensor
- 1/2.8” Progressive Scan CMOS
2 Mpx Progressive CMOS sensor - Minimum illumination
- 0.005 Lux @F1.2, 0 Lux avec IR
0.005 Lux @F1.2, 0 Lux with IR
0.005 Lux @F1.2, 0 Lux with IR - Basic functions
- OSD Menu
- Configurable OSD functions
- WDR, 3D-DNR, HLC, BLC, AGC, Masque de confidentialité, Détection de mouvement
- Lens
- 2.8 mm
2.8 mm (H: 94.5º) - Maximum resolution
- 3 Mpx (2048x1536)
- Day / Night
- Auto / Colour / BW (Black and White)
Auto / Couleur / B&N (Blanc et Noir)
Auto / Programmable / Manual - Base dimensions
- 204 x 78 mm / 4 screws
- Alarms
- 2 inputs / 2 outputs
- Remote access
- Web browser, Safire Control Center Smartphone App and PC Software
- Main Stream rate
- 640 x 480 (1 ~ 25 FPS)
- Compression
- H265+ / H.265 / H.264+ / H.264 / MJPEG
- IR range
- Up to 20 m
- Interoperability
- ONVIF
- People counting
- Statistics for entries, exits and transits | Daily, weekly, monthly and annual reports
- Intelligent functions
- Intrusion, motion detection, abandoned object, line crossing, face detection, people counting,
- Temp. fonctionnement
- -40º C ~ +60º C
- Lens Adjustment
- 3 Axis
- Recommended installation
- Installation height: 3.0 m | Detection area: 2.2 m Installation height: 3.5 m | Detection area: 3.1 m Installation height: 4.0 m | Detection area: 4.0 m Installation height: 4.5 m | Detection area: 4.8 m Installation height: 4.7 m |
- Infrared Illumination
- 20 m
- Communication interface
- 1 x Ethernet 10/100M BaseT | 1 x RS485
- Storage
- Slot for Micro SD card up to 256 GB (not included)
- Illumination
- 0.005 Lux @F1.6
- Positionnement de l\'objectif
- 3 axes
- Gamme IR
- Jusqu\'à 20 m
The Ferguson Ariva T20 receiver is compatible with the latest transmission technologies (DVB-T2 or TDT2). These technologies will soon be widely used due to the very good image quality of the DVB-T2 standard.
