Flange HellermannTyton T18R 100x2.5 PA66 NA 100
search
  • Flange HellermannTyton T18R 100x2.5 PA66 NA 100
  • Flange HellermannTyton T18R 100x2.5 PA66 NA 100
  • Flange HellermannTyton T18R 100x2.5 PA66 NA 100

100 HellermannTyton T18R 100x2,5 PA66 NA 100 Flanges

Características do produto

  • Disponível em uma ampla gama de materiais, cores e tamanhos
  • Feito de plástico de alta qualidade 100%, permitindo uma boa reciclagem
  • dentes internos fortes e de aperto um pacote
  • Fácil de aplicar manualmente ou com ferramenta
  • Inserção simples devido à flexão da sua ponta

Aprovações e reconhecimentos

1,48 €
Com IVA
Referência ht-111-01919
Marca HellermannTyton
Quantidade
Disponível em 2/3 dias

Free shipping
Flange HellermannTyton T18R 100x2.5 PA66 NA 100

100 HellermannTyton T18R 100x2,5 PA66 NA 100 Flanges

1,48 €

Features

  • Available in a wide range of materials and sizes
  • High tensile strength with very low insertion force
  • Only high quality plastic is used meeting recycling targets
  • Inside serrated cable ties for a strong hold onto bundles
  • Ergonomic bent tail offers quick and simple installation
  • Easy application either manually or with an application tool

Certifications & Approvals

Application

These cable ties are used for routing, bundling and securing of cables, pipes and hoses.

T-Series in PA66 natural is suitable for following markets and industries

  • Solar Energy SectorSolar Energy Sector
  • Wind Energy SectorWind Energy Sector
  • Rail Transportation SectorRail Transportation Sector
  • Electronics IndustryElectronics Industry
  • Aerospace IndustryAerospace Industry
  • ShipbuildingShipbuilding
  • Defence IndustryDefence Industry

Base Data

Application Tool MK3PNSP2, MK3SP, MK20, EVO7
Colour Natural (NA)
Description Short (BMEcat) (max. 150 characters) Cable Tie 100x2.5 natural
Fixation Method None
Global Part Name T18R-PA66-NA
Identification Plate Position none
Manufacturer Type T18R PA66 NA 100
Pack Cont. 100pcs.
Product Family T-Series in PA66 natural
Product Group Cable Ties Polyamide 6.6 standard
Quantity per Bag
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T18R.NN3P
Variant Inside Serrated

Product Dimensions

Bundle ∅ max. 22mm
Bundle ∅ min. 1.5mm
Length (L) 100.0mm
Min.Tensile Strength 80N
Thickness (T) 1.0mm
Width (W) 2.5mm

Material and Specifications

ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Halogenfree Yes
Hazardous goods No
Material Polyamide 6.6 (PA66)
Operating Temperature - °C -40 °C to +85 °C, (+105 °C, 500 h)
Specifications UL | ANSI/UL 746B, UL | ANSI/UL 1565, UL | ANSI/UL 62275, DNV GL | IEC 62275:2006
Specifications 99593_All_Languages.jpg99595_All_Languages.jpg625946_All_Languages.jpg94528_All_Languages.jpg844489_All_Languages.jpg
UL OCD link ZODZ2.E85319
UL-File Number E85319 [Canada]
