SAT TAS 2400 40 dB amplifier 2 Triax outputs

This module allows to filter and amplify signals of FI (Satellite) and mix with terrestrial signals. It has an attenuator and an equalizer as well as the possibility of feeding an LNB (0 - 12 VDC)

€91.48
Tax included
Reference triax-324845
Brand Triax
Quantity
Available in 4/5 days

Free shipping

SAT TAS 2400 40 dB amplifier 2 Triax outputs

€91.48

Este módulo permite filtrar y amplificar señales de FI (Satélite) y mezcla con las señales terrestres. Dispone de atenuador y un ecualizador así como la posibilidad de alimentar a un LNB (0 - 12 VDC)

Specifications

EAN number

5702663248458

Input

Input frequency range

950 - 2400 (SAT) MHz

Loop through

No

TV coupling input

-2 dB

Output

Output level

120 dBµV

Gain

40 dB

Selectivity

>= 35 (at 862 MHz) dB

Attenuation

0 - 20 dB

Equalisation

0 - 10

Noise figure (typical)

6 dB

Power supply

12-24 VDC

Power Consumption

150 mA

Mechanical data

Connectors

F-socket bases

Dimensions LxWxH

225 x 65 x 30 mm

Weight

460 g

Standard

DIN 45004B -35 dBc

Remarks

DIN 45004B: 3 IMD3 carrier waves at -60 dB.

DIN 45004K: 3 IMD3 carrier waves at -54 dB.

Available accessories

TAS



Example of chassis mounting



chasis
