SAT TAS 2400 Amplificateur 40 dB 2 sorties Triax

Ce module permet de filtrer et d'amplifier les signaux FI (Satellite) et de les mixer avec les signaux terrestres. Il possède un atténuateur et un égaliseur ainsi que la possibilité d'alimenter un LNB (0 - 12 VDC)

91,48 €
TTC
Référence triax-324845
Marque Triax
Quantité
Disponible dans 4/5 jours

Free shipping

SAT TAS 2400 Amplificateur 40 dB 2 sorties Triax

91,48 €

Ce module permet de filtrer et d'amplifier les signaux FI (Satellite) et de les mixer avec les signaux terrestres. Il possède un atténuateur et un égaliseur ainsi que la possibilité d'alimenter un LNB (0 - 12 VDC)

Spécifications

EAN number

5702663248458

Input

Input frequency range

950 - 2400 (SAT) MHz

Loop through

No

TV coupling input

-2 dB

Output

Output level

120 dBµV

Gain

40 dB

Selectivity

>= 35 (at 862 MHz) dB

Attenuation

0 - 20 dB

Equalisation

0 - 10

Noise figure (typical)

6 dB

Power supply

12-24 VDC

Power Consumption

150 mA

Mechanical data

Connectors

F-socket bases

Dimensions LxWxH

225 x 65 x 30 mm

Weight

460 g

Standard

DIN 45004B -35 dBc

Remarks

DIN 45004B: 3 IMD3 carrier waves at -60 dB.

DIN 45004K: 3 IMD3 carrier waves at -54 dB.

Accessoires disponibles

TAS



Exemple de montage sur châssis
