Data sheet

Power

DC 12 V, 3.33 A / 14W, PoE (802.3af)

Temp. operation

-10º C ~ +55º C

Degree of protection

IP66 / Surges 6000V

Audio

Microphone and speaker incorporated 1 input (Line In) / 1 output (Line Out)

Image sensor

1/1.8\" Progressive Scan CMOS Night Color

Minimum illumination

0.0005 Lux / Color 24/7

Lens

4 mm

Maximum resolution

4 Megapixel (2560x1440)

Image improvements

BLC, HLC, 120dB WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI

Day / Night

Removable mechanical ICR filter

Manual speed

Horizontal: 60°/s | Vertical: 50°/s

Alarms

1 input / 1 output + Audible and visual alarm

Internal memory

MicroSD card, Max 256 GB

Remote access

Web browser, Safire Control Center Smartphone App and PC Software

Compression

H.265+/ H.265 / H.264+/ H.264

Network interface

Ethernet 10 / 100M BaseT

Main Stream coding

4 Mpx (2560x1440) 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

Video analysis

VCA: Line crossing | Face detection | Area intrusion | Object removal detection | Abandoned object | Audio exception

Interoperability

ONVIF, PSIA, CGI

Digital zoom

16X

Electronic shutter

1/1s~1/30,000s

PTZ Control

Through network access

Advanced functions

TrueSense with false alarm filtering for vehicles and people | Line Crossing | Intrusion Face Capture: Detecting and capturing up to faces at a time. Face Tracking: Face detection and tracking

Dimensions (without bracket)

182 (H) x 120 (Ø) mm

Weight (without bracket)

1125 g

FOV

Horizontal: 88.7°, Vertical: 46.5°, Diagonal: 105.

Sub-Stream Encoding

25 fps (704 × 576, 640 × 480, 352 × 288)

White Ligth

White light Range 30m
