Wooden coil 500m Burial coaxial cable 1/2" 7RtC UV Resident Dca Class A Ø 2.7/11.5/15.0mm Gray Televes

Coaxial cable with both conductors made of copper 100% (Cu/Cu) and excellent braid coverage (77%). Includes a petro-gel layer and an external UV-resistant LSFH coverage, which makes it perfect for indoor and outdoor installation, specially for underground use, free of deformations and degradations that could affect the quality of the transported signal. A 7 RtC cable with double shielded.

€113.59 €174.75 Save 35%
Tax included
Reference televes-214001
Brand Televes
Quantity
Available in 24/48h

Free shipping
Uniarch UV-IPC-B124-PF28 - 4 MP IP Camera, Uniarch range, 1/2.7\" Progressive Scan…

Wooden coil 500m Burial coaxial cable 1/2" 7RtC UV Resident Dca Class A Ø 2.7/11.5/15.0mm Gray Televes

€113.59 €174.75 Save 35%

Coaxial cable with both conductors made of copper 100% (Cu/Cu) and excellent braid coverage (77%). Includes a petro-gel layer and an external UV-resistant LSFH coverage, which makes it perfect for indoor and outdoor installation, specially for underground use, free of deformations and degradations that could affect the quality of the transported signal. A 7 RtC cable with double shielded.

Stands out for

  • Copper conductors
  • Class A shielded
  • Dca-s2,d2,a1 Euroclass
  • Petro-gel layer

Main Features

  • Grey-colour external UV-resistant LSFH sheath
  • 75 Ohm characteristic impedance
  • 500 m wood reel

Specifications

Type 1/2”
Standard EN 50117-2-5
Euroclass Dca
Euroclass: Smoke Production s2
Euroclass: Flaming droplets d2
Euroclass: Acidity a1
Class A
Inner conductor Diameter mm 2.7
Inner conductor Material Copper (Cu)
Inner conductor Resistance Ω/km <3.2
Dielectric Diameter mm 11.5
Dielectric Material Foam polyethylene (PEE)
Dielectric Color White RAL 9003
Overlapped foil Copper + Polyester
Braid Material Copper
Braid dimensions: No. of carriers (Nc) 24
Braid Dimensions: No. of strands per carrier (Ns) 8
Braid Dimensions: strand diameter (Ø) mm 0.12
Braid Resistance Ω/km <7
Braid Coverage % 77
2nd foil No
2nd foil glued to the dielectric No
Petrol-Jelly Yes
Anti-migrating film No
Outer sheath Diameter mm 15
Outer sheath Material LSFH, UV-resistant
Outer sheath Thickness mm 1
Minimum bending radius mm 75
Transfer impedance (5-30MHz) mΩ/m <5
1GHz shielding dB > 85
Spark Test Vac 8000
Capacitance pF/m 55
Impedance Ω 75
Velocity ratio % 82
Operating temperature °C -25 ... 70
Frequencies
5 MHz 47 MHz 54 MHz 90 MHz 200 MHz 500 MHz 698 MHz 800 MHz 862 MHz 950 MHz 1000 MHz 1220 MHz 1350 MHz 1750 MHz 2050 MHz 2150 MHz 2200 MHz 2300 MHz 2400 MHz 3000 MHz
Attenuation (typ.) dB/m
0.01 0.02 0.02 0.02 0.03 0.06 0.07 0.08 0.08 0.08 0.09 0.09 0.11 0.12 0.13 0.12 0.12 0.14 0.15 0.14
2021-10-15

Data sheet

Weight
190 g
Power
DC 12 V / 4.5 W, PoE IEEE802.3af
Temp. operation
-30º C ~ 60º C
Degree of protection
Weatherproof IP67
Dimensions
142.1 (H) x 62.4 (W) x 65.2 (D) mm
Range
Uniarch
Audio
No
Image sensor
1/2.7” Progressive Scan CMOS
Minimum illumination
0.02 Lux (Colour)
Lens
2.8 mm
Maximum resolution
4 Megapixel (2560x1440)
Image improvements
DWDR, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR
Day / Night
Mechanical ICR filter
Alarms
No
Internal memory
No
Remote access
Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
Main Stream rate
4 Mpx (1 ~ 20 FPS)
Extra Stream rate
720p (1 ~ 20 FPS)
Compression
Ultra265/H.265/H.264
Network interface
Ethernet 10/100 BaseT
Interoperability
ONVIF
Infrared range
30 m
