Digital, 3in1 Single Channel FULL HIGH DEFINITION MPEG4 modulator with 3 SELECTABLE modulation SIGNALS (DVB-C, DVB-T & ISDB-T). With input from any HDMI source (Terrestrial & Satellite decoders, cameras, DVD, DVR etc.) it modulates and produces selectable output by choosing one out of THREE (3) signals: DVB-C, DVB-T & ISDB-T, depending on the installation signal, with simple adjustment using the 6 buttons and the 4-digit LED display. It offers High Output Resolution up to 1080p @ 30FPS and excellent image quality. Easy and fast PLUG & PLAY installation plus rapid adjustment with the Fast Pre-Config function among 50 selectable IDs for absolute flexibility of configuration, according to three installation signals (DVB-C, DVB-T & ISDB-T) and the number of modulators in the installation.

Features

• Digital single-channel HDMI Modulator to DVB-C, DVB-T or ISDB-T/MPEG4
• INPUT signal: HDMI
• OUTPUT signal: Cable DVB-C, Digital Terrestrial DVB-T MPEG4 or ISDB-T MPEG4
• High Video Resolution up to 1080p@30FPS
• Aspect Ratio 16:9 wide screen, 4:3 letter box, 4:3 pan scan
• Frequency Range DVB-C: 47-862 MHz
• Frequency Range DVB-T: VHF (CH.5-12) & UHF (CH.21-69)
• Frequency Range ISDB-T: VHF (CH.7-13) & UHF (CH.14-69)
• RF Output Level: Factory default 90 dbμV, with adjustable gain up to +6dbμV or attenuation up to -14dbμV
• MER: >35dB at Maximum RF output level
• Symbol Rate Up to 31.668 MBPS
• Bandwidth: 6MHZ, 7MHZ, 8MHZ
• Video Encoder: MPEG1, MPEG2 MP@HL , MPEG4 SP@L3 to ASP@L5, MPEG4 AVC HP @level4.1, MP@level4.1
• Audio Encoder: MPEGI L1/2, MPEGII LII, AAC LC, HE-AAC v1/v2 (2-CH)
• Processor System: CPU 200MHz 32Bits RISC
• Memory DDRII 16bit 512Mbits (Embedded) & NOR Flash 32Mbit
• Input HDMI v1.4a
• USB Type USB 2.0 HOST
• Fast Pre-Config Function / 50 IDs Selectable
• Backup Config File by USB
• Software Upgrade via USB
• Ports: HDMI IN, RF OUT, USB, DC 5V, GROUND
• 4-digit LED display
• 6-display buttons
• Power supply unit type: Adapter Input:100~240V AC, Output: DC 5V/2.0A
• Low Power Consumption in normal working mode: 10W maximum

Package includes

• HDMI Modulator 3in1
• Power Supply Unit 5V/2.0A
• Mounting screws
• User Manual EN/DE/GR/ES/IT/FR

General

• Dimensions: 147x105x28 mm
• Weight: 0,5 kg
• Color: black
• Warranty: 2 years

Application example
