Triax KOKA 99 HD Plus LSZH 11PAtC PE Classe A Bobina cable coaxial 250m negro

Triax KOKA 99 HD Plus LSZH 11PAtC PE Classe A. Bobina cable coaxial 250m. Negro. Cumplen con la normativa, Clasificado según CPR EN50575 Firestandard Cca.

4,54 €
Impuestos incluidos
Referencia triax-731080
Marca Triax
Cantidad
Disponible ahora

Free shipping
Uniarch UV-IPC-T122-PF28 - Cámara IP 2 Megapixel, Gama Uniarch, 1/2.9\"…

Triax KOKA 99 HD Plus LSZH 11PAtC PE Classe A Bobina cable coaxial 250m negro

4,54 €

También podría interesarle

Triax KOKA 99 HD Plus LSZH 11PAtC PE Classe A. Bobina cable coaxial 250m. Negro.
Clasificado según CPR EN50575 Firestandard Cca. Cumplen con la normativa CPR que regula los límites de resistencia al fuego y sustancias peligrosas en materiales utilizados en la construcción.

Especificaciones

ORDER INFORMATION
EAN Number 5702667310809
CONSTRUCTION
Inner conductor - material Cu
Inner conductor - dimension 1.63 ± 0.02 mm
Dielectric - material Foam PE
Dielectric - dimension 7.11 ± 0.15 mm
1. Shield foil – material Alu/PET/Alu
2. Shield braid - material Alu
2. Shield braid - coverage 60 %
Jacket - material PE
Jacket – dimension 10.03 ± 0.2 mm
CHARACTERISTICS
Type 11 PAtC
LOSS
Attenuation (20°C/100mtr) @ 5 MHz 1.25 dB
Attenuation (20°C/100mtr) @ 50 MHz 3.15 dB
Attenuation (20°C/100mtr) @ 200 MHz 6.23 dB
Attenuation (20°C/100mtr) @ 400 MHz 8.53 dB
Attenuation (20°C/100mtr) @ 800 MHz 12.0 dB
Attenuation (20°C/100mtr) @ 862 MHz 13.05 dB
Attenuation (20°C/100mtr) @ 1000 MHz 14.27 dB
RETURN LOSS
Structural return loss @ 5-470 MHz ≥ 22 dB
Structural return loss @ 470-1000 MHz ≥ 20 dB
ELECTRICAL
Impedance 75 ± 3 Ω
Capacity 53 ± 3 pF/m
Velocity ratio 85 %
OPERATIONAL
Suitable for 711571 - F-compression connector RG11-CX3-10.5 QM, 25 pcs. box
92335 - Hardline Connector GGz 2040 - 3.5/12M
Application Outdoor
Fire Class EN 50575 (Fca)
DoP number TR0108
MECHANICAL
Cable length 250 m
Packaging Height 0,001 m
Packaging Width 0,001 m
Packaging Depth 0,001 m
Net Weight 0,070 kg
Total Weight 0,070 kg

Ficha técnica

Peso
270 g
Potencia
DC 12 V / 3.5 W, PoE IEEE802.3af
Temp. funcionamiento
-30º C ~ 60º C
Grado de protección
Impermeable IP67
Dimensiones
118.1 (Al) x 96.6 (An) mm
Gama
Uniarch
Audio
No dispone
Sensor de imagen
1/2.9” Progressive Scan CMOS
Iluminación mínima
0.02 Lux (Color)
Óptica
2.8 mm
Resolución máxima
2 Megapixel (1920x1080)
Mejoras de imagen
DWDR, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR
Día / Noche
Filtro mecánico ICR
Alarmas
No dispone
Almacenamiento interno
No dispone
Acceso remoto
Navegador Web, Software CMS (EZStation), Smartphone (EZView/EZLive)
Tasa Main Stream
2 Mpx (1 ~ 25 FPS)
Tasa Extra Stream
4CIF (1 ~ 25 FPS)
Compresión
Ultra265/H.265/H.264
Interfaz de red
Ethernet 10/100 BaseT
Interoperabilidad
ONVIF
Alcance Infrarrojos
30 m
