Triax KOKA 99 HD Plus LSZH 11PAtC PE Classe A Coaxial cable reel 250m black

Triax KOKA 99 HD Plus LSZH 11PAtC PE Classe A. Coaxial cable coil 250m. Black. They comply with the regulations, Classified according to CPR EN50575 Firestandard Cca.

€4.54
Tax included
Reference triax-731080
Brand Triax
Quantity
Available Now

Free shipping
Uniarch UV-IPC-T122-PF28 - 2 MP IP Camera, Uniarch range, 1/2.9\" Progressive Scan…

Triax KOKA 99 HD Plus LSZH 11PAtC PE Classe A Coaxial cable reel 250m black

€4.54

You might also like

Triax KOKA 99 HD Plus LSZH 11PAtC PE Classe A. Coaxial cable coil 250m. Black.
Classified according to CPR EN50575 Firestandard Cca. They comply with the CPR regulation that regulates the limits of resistance to fire and dangerous substances in materials used in construction.

Specifications

CONSTRUCTION
Inner conductor - material Cu
Inner conductor - dimension 1.63 ± 0.02 mm
Dielectric - material Foam PE
Dielectric - dimension 7.11 ± 0.15 mm
1. Shield foil - material Alu / PET / Alu
2. Shield braid - material Alu
2. Shield braid - coverage 60%
Jacket - material PE
Jacket - dimension 10.03 ± 0.2 mm
CHARACTERISTICS
Type 11 PAtC
LOSS
Attenuation (20 ° C / 100mtr) @ 5 MHz 1.25 dB
Attenuation (20 ° C / 100mtr) @ 50 MHz 3.15 dB
Attenuation (20 ° C / 100mtr) @ 200 MHz 6.23 dB
Attenuation (20 ° C / 100mtr) @ 400 MHz 8.53 dB
Attenuation (20 ° C / 100mtr) @ 800 MHz 12.0 dB
Attenuation (20 ° C / 100mtr) @ 862 MHz 13.05 dB
Attenuation (20 ° C / 100mtr) @ 1000 MHz 14.27 dB
RETURN LOSS
Structural return loss @ 5-470 MHz ≥ 22 dB
Structural return loss @ 470-1000 MHz ≥ 20 dB
ELECTRICAL
Impedance 75 ± 3 Ω
Capacity 53 ± 3 pF / m
Velocity ratio 85%
OPERATIONAL
Suitable for 711571 - F-compression connector RG11-CX3-10.5 QM, 25 pcs. box
92335 - Hardline Connector GGz 2040 - 3.5 / 12M
Application Outdoor
Fire class EN 50575 (Fca)
DoP number TR0108
MECHANICAL
Cable length 250 m
Packaging Height 0.001 m
Packaging Width 0.001 m
Packaging Depth 0.001 m
Net Weight 0.070 kg
Total Weight 0.070 kg

Data sheet

Weight
270 g
Power
DC 12 V / 3.5 W, PoE IEEE802.3af
Temp. operation
-30º C ~ 60º C
Degree of protection
Weatherproof IP67
Dimensions
118.1 (H) x 96.6 (W) mm
Range
Uniarch
Audio
No
Image sensor
1/2.9” Progressive Scan CMOS
Minimum illumination
0.02 Lux (Colour)
Lens
2.8 mm
Maximum resolution
2 Megapixel (1920x1080)
Image improvements
DWDR, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR
Day / Night
Mechanical ICR filter
Alarms
No
Internal memory
No
Remote access
Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
Main Stream rate
2 Mpx (1 ~ 25 FPS)
Extra Stream rate
4CIF (1 ~ 25 FPS)
Compression
Ultra265/H.265/H.264
Network interface
Ethernet 10/100 BaseT
Interoperability
ONVIF
Infrared range
30 m
