Triax Antenna DIGI 343 LTE 700 MHZ 21-48, connection F

The Digi 343 21-48 is optimized for maximum gain in the 470-694 MHz frequency area. Above 694 MHz, the antenna shuts down, protecting the installation against LTE 700/800 interference. The Digi 343 E21-48 detects the same features that have made other TRIAX antennas a success, including: (LTE is a trademark of ETSI).

€4.54
Tax included
Reference triax-108962
Brand Triax
Quantity
Available Now

Free shipping
Uniview Pro UV-IPC3232SB-ADZK-I0 - 2 MP IP Camera, Prime range, 1/2.8\" Progressive Scan…

Triax Antenna DIGI 343 LTE 700 MHZ 21-48, connection F

€4.54

You might also like

Digi 343 LTE700, 21-48, F-conn

The Digi 343 21-48 is optimised for maximum gain in the frequency area 470-694 MHz. Above 694 MHz the antenna rollsoff, protecting the installation against LTE 700/800 interferences. The Digi 343 E21-48 spots the same features that has made other TRIAX antennas a success including:  (LTE is a trademark of ETSI)

  • Easy installation
  • High performance antenna
  • Stable and strong construction
  • Specially designed for HDTV digital reception
  • F-connector

The innovative folding structure reduces space requirement and improves logistics. The Digi 343 E21-48 is approved to carry the “LTE Protected – by TRIAX” logo

Remember to use Class A or Class A+ shielded coax cable to further secure your TV system from LTE interference.

Suitable for poles with diameter Ø32-Ø55mm.

Specifications

FREQUENCY
Band UHF
Channels 21...48
Frequency range UHF 470...694 MHz
LTE protection @ 700Mhz
GAIN
Gain 11...15 dBi
Gain @ 602 MHz (Ch. 37) 15 dBi
Gain @ 694 MHz (Ch. 48) 11.5 dBi
LOSS
Rejection @ 758 MHz (Ch. 56) 13 dB
Rejection @ 788 MHz (Ch. 60) 15 dB
ELECTRICAL
Front to back ratio - horizontal 15-25 dB
Impedance 75 Ω
MECHANICAL
Elements 26
Windload @42 m/s 150 N
Beamwidth horizontal ±19 °
Beamwidth vertical ±23 °
Main material Aluminium
Product Length 1067 mm
Packaging Height 1,060 m
Packaging Width 0,210 m
Packaging Depth 0,125 m
Packaging Volume 0,028 m3
Net Weight 2,000 kg
Tara Weight 0,500 kg
Total Weight 2,500 kg

Data sheet

Weight
920 g
Power
DC 12 V / 7.5 W, PoE IEEE802.3af
Temp. operation
-30º C ~ 60º C
Degree of protection
Waterproof IP67, Vandal-proof IK10, Surge protection
Dimensions
148 (d) x 111.4 (W) mm
Range
Prime
Audio
1 IN / 1 OUT | Integrated microphone
Image sensor
1/2.8” Progressive Scan CMOS
Minimum illumination
0.0005 Lux (Colour)
Lens
2.7~13.55mm Motorised auto-focus
Maximum resolution
2 Megapixel (1920x1080)
Image improvements
WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR
Day / Night
Mechanical ICR filter
Alarms
1 Input / 1 Relay
Internal memory
MicroSD card, Max 256 GB
Remote access
Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
Main Stream rate
1080p (1 ~ 30 FPS)
Extra Stream rate
2º:720p (1 ~ 30 FPS), 3º:D1 (1 ~ 30 FPS)
Compression
Ultra265+/H.265/H.264
Network interface
Ethernet 10/100 BaseT
Interoperability
ONVIF
Intelligent functions
Crossover, Perimeter Protection, Motion Detection, Audio Detection, Tamper Protection, Corridor Mode
Infrared range
40 m
Video Backup
ANR video recovery technology by installing a Micro SD card
