SELECT * FROM ps_od_oosbutton_manufacturer WHERE id_manufacturer = 22SELECT * FROM ps_od_oosbutton JOIN ps_od_oosbutton_lang USING (id_product) WHERE id_product = 21803 AND id_lang = 1 Triax D5A 11 B Directional antenna for 4G/5G signal reception (G11 dBi) Includes 7 meter cable Black
Uniview Pro UV-IPC6252SL-X33UP - 2 MP Motorised IP Camera, Pro range, 1/2.8”…
search
  • Uniview Pro UV-IPC6252SL-X33UP - 2 MP Motorised IP Camera, Pro range, 1/2.8”…

Triax D5A 11 B Directional antenna for 4G/5G signal reception (G11 dBi) Includes 7 meter cable Black

Directional antenna for 4G/5G signal reception. Work, rest or play online reliably and quickly, wherever you’re staying – TRIAX 5G antennas boost mobile broadband reception in places fibre doesn’t reach. Simply connect to your choice of mobile broadband router to receive the maximum attainable mobile network speed at each location.

€10.21
Tax included
Reference triax-109600
Brand Triax
Quantity
Available Now

Free shipping
Uniview Pro UV-IPC6252SL-X33UP - 2 MP Motorised IP Camera, Pro range, 1/2.8”…

Triax D5A 11 B Directional antenna for 4G/5G signal reception (G11 dBi) Includes 7 meter cable Black

€10.21

You might also like

Directional antenna for 4G/5G signal reception.

Future-proof connectivity, wherever you are

Work, rest or play online reliably and quickly, wherever you’re staying – TRIAX 5G antennas boost mobile broadband reception in places fibre doesn’t reach.

Simply connect to your choice of mobile broadband router to receive the maximum attainable mobile network speed at each location. The 11 dB gain ensures outstanding signal quality.

The antennas are ready for the advancing 5G roll-out across Scandinavia, bringing speeds up to 100x faster than 4G. They are fully compatible with all mobile signals: use the best possible 4G LTE speeds now, with no need for future upgrades when 5G arrives.

For the ultimate in speed and reliability, our antennas are MIMO compatible. We recommend installing a pair of directional antennas 70 cm apart and at 45° opposing angles.

The antenna is delivered with 7m black cable with connector, which is ready for mounting directly on the router.

Specifications

CHARACTERISTICS
Antenna type directional
Antenna use outdoor
Polarization vertical or horizontal
MIMO Yes by the use of 2 antennas
FREQUENCY
Frequency range 698-960/1710-2700/3300-3600/4800-5000 MHz
Services GMS/Wi-Fi/3G/4G/LTE/5G - (5G low band)
GAIN
Gain 10...11 dBi
VSWR < 2.5
ELECTRICAL
Front to back ratio - horizontal > 21 dB
Impedance 50 Ω
OPERATIONAL
IP rating 65
Lightning protection DC ground on the antenna
Temperature - operating -40... +60 °C
CONNECTORS
Connector Type SMA-male
Output cable type PVC black low loss coaxial cable
MECHANICAL
Beamwidth horizontal 60 °
Beamwidth vertical 55 °
Diameter of installation pole 30-53 mm
Bracketry with wingnuts
Main material Plastic housing ABS
Colour RAL 1013 - White
Packing QTY 1
Product Height 210 mm
Product Length 445 mm
Product Depth 70 mm
Packaging Height 0,568 m
Packaging Width 0,217 m
Packaging Depth 0,087 m
Packaging Volume 0,011 m3
Net Weight 1,180 kg
Tara Weight 0,235 kg
Total Weight 1,415 kg

Data sheet

Power
DC 24 V / AC 24 V / 47W, PoE+ IEEE802.3at
Resolution
2 Megapixel (1920x1080)
Temp. operation
-40º C ~ +70º C
Degree of protection
Weatherproof IP66
Video output
RJ45
Audio
1 Input / 1 Relay
Image sensor
1/2.8\" Progressive Scan CMOS
Minimum illumination
0.001 Lux (Colour)
Lens
Varifocal 4.5~148.5mm (Optic Zoom 33X)
Infrared lighting
IR Laser 500 meters
Image improvements
BLC, HLC, EIS, WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI, ANR
Day / Night
Mechanical ICR filter
Pan/Tilt Range
Horizontal: 0°~360°, Vertical: -15°~90° auto flip
Preset positions
1024 preset, preset patrol, route patrol, recorded patrol
Alarms
1 IN / 1 OUT
Internal memory
MicroSD card, Max 256 GB
Remote access
EZStation Web Browser, Smartphone App and PC Software
Compression
Ultra265/H.265/H.264
Network interface
Ethernet 10 / 100 BaseT
Interoperability
ONVIF, PSIA, CGI
Digital zoom
16X
Electronic shutter
1/1s~1/100,000s
Speed between Presets
Horizontal: 300° /s, Vertical: 240° /s
Smart Features
People counting, Face detection, Line crossing, Intrusion detection, Auto tracking, Audio detection, Reiterated object, Abandoned object
Dimensions (without bracket)
359.4 mm (H) x 227 (Ø) mm
Weight (without bracket)
5600 g
Speed
Horizontal: 0.1° ~ 240°/sec, Vertical: 0.1° ~160°/s
