Data sheet

Power

DC 12V / 3A

Type

Software

Dimensions / Weight

55 (H) x 325 (W) x 257 (D) mm / 1.3 Kg

Communication

RS485 (PTZ) /2 x USB (Mouse and backup) / RJ45 10/100/1000 (Ethernet)

Compatibility

People Counting Cameras (Safire, Uniview and X-Security)

Video format

HDTVI / HDCVI / AHD / CVBS / IP

Video inputs

16 Channels BNC (HDTVI / HDCVI / AHD / CVBS)

Bidirectional audio

Reusing the audio input/output

Total bandwidth

128 Mbps

Simultaneous multifunction

Pentaplex: Live, Recording, Playback, Backup and Remote Access

Recording method

Manual, programmed, motion detection, alarm

Internal memory

1 SATA HDD 3.5\" of up to 10 TB (not included)

Remote access

Web browser (ActiveX), mobile phone application or PSS software

Video outputs

1 HDMI 1080p, 1 VGA

Video / audio compression

H.265+/H.265/H.264+/H.264

Main Stream coding

K (7FPS) or 6MP (10FPS) or 5MP (12FPS) or 4K-N/4MP/3MP (15FPS) or 4M-N/1080p/720P (25/30FPS)

Hybrid configuration

Up to 32 IP Channels (8Mpx), replacing all the BNC channels

Audio inputs

16 Channel RCA

Audio outputs

1 Channel RCA

Recording resolution

4K, 6MP, 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, VAT

Extra Stream coding

:960H(1fps–15fps) or D1/CIF(1fps–25/30fps)

Backup

USB / Network

Video analysis

IVS: Tripwire | Area intrusion | Abandoned object | Face detection

Installation

Windows x64, Linux x64 and Linux arm64

Alarms IN/OUT

16 inputs / 3 Relay

Quantity

Up to 20 People Counting cameras (possibility of expansion) and 1 room

Characteristics

Real-time capacity information, customized reports

Expiry date

Single perpetual license (can only be installed on one computer)

Intelligent motion detection

Up to 16 channels capable of classifying targets amongst humans and vehicles

Facial recognition

Up to 2 analog channels for live face comparison

Resolution HDMI display

3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 ×720
