Câble coaxial RG59 trishield 77 blindage blanc bobine int-ext 305 mètres

Bobine de 305 mètres Câble coaxial série 59 - LTE. Conducteur en acier cuivré. Diélectrique en polyéthylène expansé. Bouclier laminé APA collé. Tresse 77% aluminium. Bouclier en stratifié APA (ShieldXTM). Veste en PVC blanc. Conforme RoHS et WEEE. Conforme à la classe A + blindage, EN 50117 2-4

119,00 €
TTC
Référence T59TSFx77-U
Quantité
Disponible dans 24/48h

Free shipping
Cable coaxial RG6 trishield 80% apantallamiento blanco int-ext bobina 305 metros

Câble coaxial RG59 trishield 77 blindage blanc bobine int-ext 305 mètres

119,00 €

Ce modèle remplace le câble coaxial blindé 2605-RG59 - RG59 trishield 77

Câble coaxial de classe A + triple blindage, qui offre un transport de haute qualité de signal TV / Vidéo avec une faible interférence LTE.

Caractéristiques

  • Câble coaxial Série 6 - LTE
  • Conducteur en acier cuivré
  • Diélectrique en mousse de polyéthylène
  • Bouclier laminé APA collé
  • 77% Tresse d'aluminium
  • APA Laminate Shield (ShieldX ™)
  • Veste en PVC blanc
  • Compatible RoHS et WEEE
  • Conforme à la classe A + Blindage, EN 50117 2-4

Spécifications

Material Detail inches mm
Inner Conductor Copper-Clad Steel 0.0320 0.81
Dielectric Foamed Polyethylene 0.144 3.66
1st Outer Conductor Sealed APA Tape 0.150 3.81
2nd Outer Conductor 77% Aluminum Braid 0.175 4.45
3rd Outer Conductor APA Tape (ShieldXTM) 0.181 4.60
Floodant --- --- ---
Jacket PVC, White 0.241 6.12
Messenger --- --- ---
Mechanical Specifications
Minimum Bend Radius, in. (mm)   0.75 (19.05)
Product Weight (less reel) 24 lbs /kft 36 kg / km
Pull Force   > 10 lbf < 17 lbf > 45 N < 76 N
Tensile   ≥ 25 lbf ≥ 110 N
 Electrical Specifications
 Impedance, Ω     75 ± 3
 Velocity of Propagation, %    83
 Capacitance, Nominal  16.3 pF/ft     53.5 pF/m
 DC Resistance   Ω / kft    Ω / km
 Inner Conductor  49.2    161
 Outer Conductor  7.25     24
 Loop  56.5     185
 Structural Return Loss, dB
 5-30 MHz     -27
30-470 MHz    -27
470-1000 MHz    -24
1000-2000 MHz    -22
2000-3000 MHz    -20
RFI Shielding
Meets Class A+ Shielding, EN 50117 2-4
Transfer Impedance
5-30 MHz   ≤ 2.5 mΩ•m
Screening Attenuation
30-1000 MHz    ≥ 95 dB
1000-2000 MHz    ≥ 85 dB
2000-3000 MHz    ≥ 75 dB
 Attenuation, Maximum @ 68 °F (20 °C)
 Frequency, MHz   dB / 100 ft   dB / 100 m
 5  0.86  2.82
 55  2.05   6.73
 100  2.69   8.83
 211  3.80  12.47
 250  4.10  13.45
 270  4.22  13.85
 300  4.45  14.60
330 4.66  15.29
350 4.80  15.75
400 5.10  16.73
450 5.40  17.72
500 5.70  18.70
550 5.95  19.52
600 6.20  20.34
750 6.97  22.87
870 7.57  24.84
1000 8.12  26.64
1450 9.82  32.22
1750 10.92  35.83
2150 12.10  39.70
2250 12.38  40.62
2500 13.05  42.81
3000 14.30  46.92
